Full-surface adhesive pipe grommets that can be plastered over, for interior and exterior use

ROFLEX SOLIDO

Advantages

  • Keeps building components dry: quick and simple sealing
  • Reliable joints thanks to water-resistant SOLID adhesive
  • Practical handling: pipes can be pushed and pulled through the grommet – the joint remains sealed
  • Extremely flexible and elastic, no protruding sleeve
  • Construction in adherence with standards: for airtight sealing in accordance with DIN 4108-7, SIA 180 and RE 2020
  • Excellent values in hazardous substance testing, has been tested according to the ISO 16000 evaluation scheme

Areas of application

For quick, permanently sealed joints for pipe feed-throughs for masonry and concrete walls and ceilings and for wood fibreboards and wood-based panels, both indoors and outdoors.

Product Ø grommet For Ø pipe
ROFLEX SOLIDO 50 200 mm (7.9") 50-80 mm (2" - 3 1/8")
ROFLEX SOLIDO 100 250 mm (~10") 90-120 mm (3 1/2" - 4 3/4")
ROFLEX SOLIDO 150 296 mm (11 5/8") 120-170 mm (4 3/4" - 6 3/4")
ROFLEX SOLIDO 200 346 mm (13 5/8“) 180-220 mm (7" - 8 3/4")

Technical specs

  Material
Main product component PP backing fleece, PP copolymer special membrane, sealing ring: EPDM
Adhesive Water-resistant SOLID adhesive
Release film Silicone-coated PE film
Property Value Regulation
Colour black
Outdoor exposure 3 months
Bond durability, non-aged/aged passed DIN 4108-11
Can be plastered over yes
Installation temperature above -10 °C ; 14 °F
Temperature resistance EPDM permanent -40 °C to 150 °C ; -40 °F to 300 °F
Storage cool and dry
